Technical Specifications Power supplied by FieldPoint backplane. 8-channel digital input. 24VDC sink/source compatible. Channel isolation. Operating temperature:-40°C ~ +70°C.
Functional Features Field on/off status acquisition. Input signal filtering. Channel fault detection. Status LED per channel. Data transmission over FieldPoint network.
Application Scenarios Factory automation, remote equipment status monitoring, valve feedback and limit switch signal collection in distributed industrial sites.
Performance Parameters Wide industrial temperature range, noise filtering for contact bounce suppression. Operating temperature:-40~+70°C.
Structural Characteristics DIN rail mount plastic housing, field wiring screw terminals, backplane connector for FieldPoint network, digital signal conditioning circuit.
Working Principle Detect 24VDC discrete signal state from field switches, convert the electrical status into digital data and transmit measurement information to FieldPoint controller over the backplane bus.
Installation Requirements Clip onto DIN rail. Wire field 24V contact signals to terminal block. Add to FieldPoint project in NI configuration software.
Usage Notes Check input polarity during wiring. Protect module from inductive surge from relays and solenoids.
