Technical Specifications USB 2.0 high-speed interface. 4 slots for C Series modules. 9V to 30V DC external power input. Synchronization bus for multi-module timing. Operating temperature:0°C ~ +55°C.
Functional Features C Series module mechanical mounting and power distribution. USB data transmission between I/O modules and PC. Built-in timing and trigger routing. Module hot swapping support. Status LED indicators.
Application Scenarios Laboratory measurement, product test bench, machine condition monitoring, sensor data logging and small-scale industrial data acquisition.
Performance Parameters High-speed USB data streaming, hardware timing synchronization. Operating temperature:0~+55°C.
Structural Characteristics Compact metal enclosure, USB port, DC power terminal, four C Series module slots, internal backplane synchronization bus.
Working Principle Receive power from external DC supply. Communicate with PC through USB, transfer analog/digital signals collected by C Series modules to host software, and distribute timing trigger signals across installed modules.
Installation Requirements Mount on bench or DIN rail with optional bracket. Connect USB cable to PC and DC power supply. Install compatible C Series modules into slots.
Usage Notes Use shielded USB cable to reduce noise. Do not connect or disconnect modules under heavy measurement operation.
