Technical Specifications Configurable matrix switch channels, low on-resistance, signal relay switching, SCXI bus interface.
Functional Features Signal path routing, multi-channel signal switching, automated test sequence switching, signal isolation.
Application Scenarios Automated test equipment, semiconductor test, circuit board testing, multi-point signal routing.
Performance Parameters Low insertion loss, stable switching performance, good signal isolation between channels.
Material Composition Flame retardant plastic housing, fiberglass circuit board, signal relays, metal shielding frame, terminal block.
Structural Characteristics SCXI plug-in module structure, front terminal block for signal wiring, rear gold finger for backplane communication.
Working Principle Receives switching commands from DAQ controller, controls internal relays to change signal path and realize signal routing between different channels.
Installation Requirements Insert module into SCXI chassis slot, lock module, connect signal wires to front terminal block.
Usage Notes Limit signal current and voltage within rated range. Reduce relay switching frequency for long service life.
