Technical Specifications 32 single-ended / 16 differential analog input; 16-bit ADC; 200 kS/s sampling rate; 2 analog output channels; 8 digital I/O lines; PCI bus; Operating temperature 0~55°C.
Functional Features Multi-channel analog voltage measurement. Analog signal output. Digital input and output for logic control. Hardware trigger for synchronized sampling.
Application Scenarios General laboratory measurement, automated test bench, sensor monitoring, small scale industrial control and data logging.
Performance Parameters 16-bit resolution; Configurable input range; Hardware triggering support for synchronized acquisition.
Structural Characteristics Standard PCI board, pin terminal connector on front panel, LED status indicators.
Working Principle The board samples analog input signals via ADC, converts digital values to analog output via DAC, and reads/writes digital logic signals. All data is transferred to PC over PCI bus.
Installation Requirements Power off PC, insert PCI card. Install NI DAQmx driver. Connect signal wiring to terminal connector.
Usage Notes Check maximum input voltage limitation. Isolate high voltage signals. Configure input mode as single-ended or differential according to wiring.
