Technical Specifications 4 counter channels; Quadrature encoder input; Maximum input frequency up to 100 MHz; Digital input 5 V / 24 V compatible; Operating temperature -40°C to 70°C.
Functional Features Quadrature encoder position measurement. Pulse count and frequency measurement. Digital trigger and event capture. Support index signal for encoder zero reference.
Application Scenarios Motion control, rotary position monitoring, speed measurement, automated machinery, packaging and semiconductor equipment.
Performance Parameters High frequency response; High resolution position counting; Configurable digital filter for noise suppression.
Structural Characteristics Compact C Series module, spring terminal connector, status LED indicators, pluggable into CompactRIO chassis slots.
Working Principle The module captures digital pulse signals from encoders or pulse generators. Internal counter circuits accumulate pulse counts and calculate position, speed and frequency. Data is transferred to CompactRIO controller via backplane bus.
Installation Requirements Install module into CompactRIO chassis. Connect encoder or pulse signal wiring. Configure FPGA logic in NI LabVIEW FPGA environment.
Usage Notes Use shielded cable for high-speed pulse signals. Avoid long wiring to reduce noise interference. Verify encoder signal type before commissioning.
