Technical Specifications MPC8240 PowerPC processor; VME64x bus interface; Onboard SDRAM, flash ROM and battery-backed NVRAM; 10/100Base-TX Ethernet; Serial console port; 6U VME form factor; Operating temperature 0~70°C.
Functional Features Real-time embedded computation. VMEbus master, slave and system controller functions. PMC and PC·MIP expansion slots for custom I/O modules. ECC memory protection and watchdog timer.
Application Scenarios Industrial process control, railway control, aerospace test systems, legacy VME platform upgrade projects.
Performance Parameters Low latency real-time processing; Support A64/D64 VME64x data transfer; Battery-backed memory preserves configuration during power loss.
Structural Characteristics Single-width 6U VME board, front panel Ethernet and serial ports, VME P1/P2 backplane connectors, status LED indicators.
Working Principle The PowerPC processor executes embedded firmware and application programs. It communicates with other VME modules via VME64x backplane bus, and provides external communication via Ethernet and serial ports. Mezzanine slots extend I/O capability.
Installation Requirements Insert board into 6U VME chassis slot and secure front panel ejector latches. Use anti-static wrist strap during handling. Install required PMC/PC·MIP mezzanine cards before closing chassis.
Usage Notes Cut off power before board insertion or removal. Prevent electrostatic discharge damage. Check LED status after power-up.
