Technical Specifications 68060 CPU; VMEbus master/slave; Large onboard RAM and flash; Ethernet and serial ports; 6U VME board; Operating temperature 0~70°C.
Functional Features High-speed embedded computing. VMEbus master/slave data transfer. Onboard Ethernet and serial console for network communication and debugging.
Application Scenarios High performance automatic test equipment, complex industrial control, simulation platform, legacy aerospace embedded VME systems.
Performance Parameters High CPU processing speed; Large onboard memory; Reliable VMEbus data communication.
Structural Characteristics 6U VME single board, VME backplane connector, front panel Ethernet, serial port and multi status LED indicators.
Working Principle The 68060 processor runs embedded application software. It accesses onboard memory and peripherals, exchanges data with other VME modules over VMEbus backplane, and communicates externally via Ethernet and serial ports.
Installation Requirements Insert board into 6U VME chassis slot and fasten front panel screws. Anti-static protection required during handling.
Usage Notes Power off before plugging or removing the board. Avoid electrostatic discharge damage. Check LED indicators after power on.
