Technical Specifications 68040 processor; VMEbus interface; Onboard RAM, flash ROM; Serial ports; Ethernet interface; 6U VME board; Operating temperature 0~70°C.
Functional Features High performance embedded computing. VMEbus master/slave operation. Onboard Ethernet and serial communication for network and console access.
Application Scenarios Industrial process control, test & measurement equipment, aerospace and legacy VME-based automation systems.
Performance Parameters High computing performance; Support VMEbus high-speed data transfer; Onboard network communication.
Structural Characteristics 6U VME single board, VME backplane connector, front panel Ethernet, serial ports and status LEDs.
Working Principle The 68040 processor executes embedded software. It communicates with other VME modules via VMEbus backplane, uses Ethernet and serial ports for external communication and data exchange.
Installation Requirements Insert board into 6U VME chassis slot and fix front panel screws. Anti-static protection required during installation.
Usage Notes Power off before board replacement. Prevent electrostatic discharge damage. Check LED indicators after power-up.
