Modicon AS-BDAO-216 Analog Output Module

Technical Specifications 4 analog output channels, 4-20mA. Resolution:12bit. Power supply:24VDC. Operating temperature:0~+60°C.

Functional Features 4-channel analog current output. Short-circuit protection. Output value monitoring. Self-diagnosis and LED alarm.

Application Scenarios Process valve positioning, variable speed drive analog setpoint output, industrial continuous regulation.

Performance Parameters Accuracy ±0.3%FS, resolution 12bit. Operating temperature:0~+60°C.

Structural Characteristics Rack mount analog output module, front LED indicators, output terminal block.

Working Principle Receive digital control value from PLC CPU, use DAC circuit to convert digital signal to 4-20mA analog current signal for field actuator.

Installation Requirements Install on Modicon 800 rack. Use shielded cable to connect to control valve positioner.

Usage Notes Perform output calibration regularly. Prevent short circuit on output wiring.
