Modicon AS-B836-016 Digital Transistor Output Module

Technical Specifications 16 output channels, 24VDC transistor output. 0.5A per channel. Operating temperature:0~+60°C. Group isolation.

Functional Features 16-channel high-speed transistor output. Per-channel overcurrent protection. LED state indicator. Output fault detection.

Application Scenarios Conveyors, automated machinery, DC solenoids, indicator lights control.

Performance Parameters Max single channel current:0.5A. Response time <1ms. Operating temperature:0~+60°C.

Structural Characteristics Rack plug-in module, front panel LEDs, field terminal block, backplane connector.

Working Principle Receive output instructions from Modicon CPU, control transistor switch to turn on/off 24VDC field loads and report fault status.

Installation Requirements Mount in Modicon 800 rack. Use appropriate wire gauge for output loads.

Usage Notes Do not overload each channel. Add flyback diode for inductive DC loads.
