Modicon AS-B814-108 Relay Output Module

Technical Specifications 8 channels relay output. Contact rating: 120/240VAC, 2A. Power supply:24VDC logic power. Operating temperature:0~+60°C.

Functional Features 8 independent relay output points. Isolated relay contacts. LED channel status. Suitable for mixed AC/DC loads.

Application Scenarios Old Modicon control system, low power solenoid valves, alarm lamps, auxiliary relay control.

Performance Parameters Relay electrical life: 100,000 operations at rated load. Operating temperature:0~+60°C.

Structural Characteristics Rack plug-in module, front LED indicators, output terminal block, internal mechanical relays.

Working Principle CPU sends digital command, module energizes internal relay coil, relay contact closes or opens to switch field load circuit.
