Technical Specifications VXI C-size module, IEEE1394 communication interface, VXI backplane communication, powered by VXI rack.
Functional Features Serves as host controller interface for VXI test system, controls VXI instruments, transfers measurement data and triggers test sequence.
Application Scenarios Aerospace test system, semiconductor test bench, automated precision measurement laboratory test equipment.
Performance Parameters High-speed data transmission, support hardware trigger synchronization, stable control for multi-module VXI system.
Structural Characteristics C-size VXI plug-in module, metal shielding casing, front panel Firewire port and status indicators.
Working Principle Communicates with PC through IEEE1394 bus, translates commands to VXI bus signals and controls all modules inside VXI chassis.
Installation Requirements Insert into C-size VXI chassis slot, connect Firewire cable to host PC, follow ESD protection rules during handling.
Usage Notes Use anti-static wristband. Do not hot swap module when VXI chassis power is on.
