Technical Specifications Pulse output, adjustable frequency; Isolated channels; Operating temperature 0~60°C; Overload protection for output terminals.
Functional Features Generate pulse sequence and frequency output. Support pulse quantity control. Built-in channel fault detection. Hot swappable design.
Application Scenarios Positioning control and pulse driving applications in process automation, used for pulse-controlled actuators and metering equipment.
Performance Parameters Adjustable pulse frequency; High pulse output accuracy; Short-circuit protection for each channel.
Structural Characteristics Rack plug-in module with terminal block for field wiring. LED indicators for module running, communication and channel fault.
Working Principle DCS controller sends target pulse number and frequency command to module through backplane. Module generates corresponding pulse waveform and outputs to field equipment, monitors channel status.
Installation Requirements Install into DCS rack and lock module. Use shielded cable for pulse signal wiring. Keep away from high power cables.
Usage Notes Do not plug/unplug module under power on. Set pulse parameters in DCS software. Verify load compatibility before wiring.
