Technical Specifications 16 analog input channels; 4–20 mA signal range; HART protocol pass-through support; 2 groups of 8 channels with common 0 V; DIN rail mounting; operating temperature -40°C to +85°C; IP67 rating.
Functional Features Analog signal termination; HART bidirectional communication support; signal conditioning; loop fault detection; field device power supply.
Application Scenarios Process transmitter interfacing, safety analog signal measurement, HART device integration, process control and safety system input.
Performance Parameters High signal accuracy; low signal drift; reliable HART communication; stable operation over wide temperature range.
Material Composition Industrial plastic housing, precision analog circuit components, copper alloy terminals, metal shielding structure.
Structural Characteristics Compact field mountable housing, front access terminals, HART communication interface, DIN rail mounting clips.
Working Principle Terminates 4–20 mA analog signals from field transmitters, passes HART communication signals between devices and the control system, and provides loop power and signal conditioning.
Installation Requirements Mount on standard DIN rail; connect transmitter wiring to front terminals; connect system interconnection cable to rear interface.
