Technical Specifications 16 input channels organized in 2 groups of 8; 50 V maximum voltage rating; 24 V DC nominal operation; screw terminal connections; DIN rail mounting; CE, TÜV, UL certified.
Functional Features Universal digital input termination; signal conditioning; wiring protection; channel identification; easy field connection.
Application Scenarios Safety system field wiring, digital sensor termination, emergency stop circuit interface, safety interlock wiring.
Performance Parameters Reliable signal integrity; stable connection under vibration; wide input voltage compatibility.
Material Composition High-temperature plastic housing, copper alloy screw terminals, fiberglass circuit substrate, metal mounting hardware.
Structural Characteristics Compact DIN rail mount module, clearly labeled front terminals, rear system connector, orange identification housing.
Working Principle Terminates field digital signal wiring, provides signal conditioning and overvoltage protection, and routes signals to the safety input module through the system interconnection cable.
Installation Requirements Mount on standard DIN rail; connect field sensor wiring to front screw terminals; connect system cable to rear interface connector.
