Technical Specifications 16 signal channels; 24 V DC field circuit; knife-edge disconnect terminal design; end-of-line (EOL) resistor support; DIN rail mounting; IP20 protection rating.
Functional Features Field wiring termination; signal circuit disconnect for maintenance; end-of-line termination support; wiring identification and organization; short-circuit protection fusing.
Application Scenarios Safety system field wiring interface, control cabinet termination, safety I/O system wiring, industrial process safety panels.
Performance Parameters Reliable wire connection; easy maintenance disconnect; clear channel identification; stable signal transmission.
Material Composition Flame-retardant plastic housing, copper alloy screw terminals, fiberglass terminal board, metal DIN rail mounting clips.
Structural Characteristics DIN rail mountable terminal module, labeled channel terminals, knife-edge disconnect mechanism, front-access wiring.
Working Principle Provides a physical and electrical interface between field safety device wiring and the system I/O module, enabling signal connection, circuit isolation for maintenance, and end-of-line termination for loop monitoring.
Installation Requirements Mount on standard DIN rail in control cabinet; connect field wiring to front terminals; connect system cable to rear interface; implement proper grounding.
Usage Notes Follow torque specifications for terminal screws; use designated end-of-line resistors for loop monitored channels; disconnect circuits before maintenance work.
