Technical Specifications 4 independent output channels; 24 V DC solid-state source output; 1 A maximum current per channel; 3.6 A maximum total module load; short-circuit proof; overload detection threshold above 10 Ω; cold resistance lamp detection above 20 Ω; operating temperature -20°C to +60°C.
Functional Features Continuous output loop monitoring; open and short circuit detection; watchdog timer supervision; per-channel fault diagnosis; load current sensing.
Application Scenarios Safety-critical actuator control, emergency shutdown valve control, safety interlock outputs, process safety control loops.
Performance Parameters High loop diagnostic coverage; fast fault detection response; stable output regulation; low false fault rate.
Material Composition Flame-retardant plastic housing, current-sensing output circuit board, gold-plated backplane connector, insulated terminal blocks.
Structural Characteristics Rack plug-in module, front wiring terminal block, rear system bus connector, channel fault status indicators.
Working Principle Outputs switching control signals to field actuators, continuously monitors output loop integrity through current sensing, and reports fault conditions to the safety controller.
Installation Requirements Install in Safety Manager rack slot; connect output wiring with loop-compatible field devices; configure monitoring thresholds in system engineering tool.
Usage Notes Match loop monitoring parameters to actual load characteristics; perform periodic fault simulation tests; do not exceed total module power dissipation limit.
