Technical Specifications 8 independent digital output channels; 24 V DC output voltage; 550 mA maximum current per channel; built-in suppression diodes for inductive loads; integrated watchdog timer; operating temperature -40°C to +85°C; IP65 enclosure rating; SIL 2 certified per IEC 61508.
Functional Features Safety-grade on-off control output; per-channel short-circuit protection; watchdog timer for output state supervision; inductive load surge protection; channel status feedback.
Application Scenarios Solenoid valve control, safety relay driving, indicator lamp control, emergency shutdown actuator control, process safety output circuits.
Performance Parameters Fast switching response; reliable output state supervision; long service life solid-state switching; stable operation under harsh environmental conditions.
Material Composition Reinforced plastic housing, power semiconductor circuit board, gold-plated backplane connector, copper alloy wiring terminals.
Structural Characteristics Rack plug-in module, front panel with status LEDs, rear backplane bus interface, screw terminal field wiring connections.
Working Principle Receives validated output commands from the safety controller, drives solid-state output circuits to switch field load power, and continuously monitors output state for fault detection.
Installation Requirements Insert into Safety Manager rack output slot; connect field actuator wiring to front terminal block; install external fuses for inductive loads; verify load voltage rating.
