Technical Specifications 24VDC power from carrier. 32 digital input channels. 24VDC sink/source input. Group galvanic isolation. Operating temperature:0°C ~ +60°C.
Functional Features Field discrete signal termination. Input noise filtering. Contact status transfer to DI IOM. Wire fault detection support.
Application Scenarios Power plant, chemical plant, water treatment for valve feedback, motor running status, limit switch and relay contact signal collection.
Performance Parameters Stable discrete signal sampling, anti-interference filtering. Operating temperature:0~+60°C.
Structural Characteristics IOTA PCB board, large screw terminal block, backplane connector mating with DI IOM module, signal conditioning circuit.
Working Principle Receive 24VDC discrete on/off signals from field switches and contacts, route these digital status signals to digital input IOM module for controller reading.
Installation Requirements Mount on Series-C carrier rack. Wire field contact and 24VDC sensor cables. Configure channel mapping in Control Builder.
Usage Notes Check input polarity. Protect from surge voltage from inductive field devices.
