Technical Specifications Backplane power supply. Multiple analog input channels. 4-20mA / voltage input configurable. Galvanic isolation. Operating temperature:0°C ~ +60°C.
Functional Features Analog signal acquisition. Channel fault diagnosis. Overload protection. LED status display. Hot swappable.
Application Scenarios Refinery, water treatment, pulp and paper process control for field analog instrument signal collection.
Performance Parameters Stable sampling performance, high anti-interference ability. Operating temperature:0~+60°C.
Structural Characteristics Rack mount module, front wiring terminal unit, backplane bus connector, analog signal processing circuit.
Working Principle Convert continuous analog signals from field transmitters into digital data, and upload measurement values to the DCS controller for process calculation and monitoring.
Installation Requirements Insert module into C200 rack. Connect field shielded instrument cables. Complete channel configuration download.
Usage Notes Do not exceed the rated input range. Calibrate zero and span during commissioning.
