Technical Specifications Backplane powered. Multi-channel analog input. 4-20mA / 0-10V signal support. Channel group isolation. Operating temperature:0°C ~ +60°C.
Functional Features Continuous analog signal sampling. Over-range detection. Transmitter open circuit alarm. LED channel status indication. Hot swap capability.
Application Scenarios Chemical, oil & gas, power plant for pressure, temperature, flow transmitter signal acquisition.
Performance Parameters High measurement precision, built-in signal filtering. Operating temperature:0~+60°C.
Structural Characteristics Rack pluggable module, front field wiring terminal block, backplane bus connector, multi-channel ADC conversion circuit.
Working Principle Receive analog current or voltage signals from field sensors, convert analog quantity into digital data, and transmit digital values to C200 controller through backplane bus.
Installation Requirements Install module in DCS rack. Connect shielded twisted pair cables to field transmitters. Configure signal type for each channel in control system software.
Usage Notes Use shielded cable with single-point grounding. Check wiring integrity before powering on.
