Technical Specifications Combined digital input and digital output channels; SIL3 certified; Galvanic isolation; Part number 982200484; Rack mount design.
Functional Features Digital signal detection; Safety on/off output; Short circuit and open circuit diagnosis; Fault status reporting to safety controller; Hot swap.
Application Scenarios Emergency shutdown system, safety interlock, fire and gas protection system in process plants.
Performance Parameters SIL3 safety level; Fast fault response; Independent channel diagnosis.
Structural Characteristics Pluggable rack module, front diagnostic LEDs, dedicated terminal assembly for field discrete wiring.
Working Principle Detect digital status of field sensors and switches, send status data to safety CPU. Execute safety interlock commands and drive digital output channels to actuate safety-related field devices.
Installation Requirements Mount on designated HIMax rack; Follow HIMA wiring specification; Ensure reliable grounding of control cabinet.
Usage Notes Confirm safety logic download before putting online. Perform loop test after installation. Avoid strong electromagnetic interference environment.
