Technical Specifications ISA bus interface. DeviceNet master protocol. 24VDC fieldbus power. Galvanic isolation between PC side and fieldbus. Operating temperature:0°C ~ +55°C.
Functional Features DeviceNet master bus management. Cyclic I/O data exchange with DeviceNet slaves. Bus fault diagnosis. Network status monitoring.
Application Scenarios Legacy industrial PC control system, old production line retrofitting, DeviceNet fieldbus equipment communication.
Performance Parameters Stable cyclic data exchange, bus error detection. Operating temperature:0~+55°C.
Structural Characteristics ISA form factor PCB card, DeviceNet terminal connector, isolation circuit, onboard protocol processor.
Working Principle Installed in industrial PC ISA slot. Act as DeviceNet master, establish connection with slave devices on DeviceNet bus, exchange real-time I/O data and diagnostic information between PC and fieldbus nodes.
Installation Requirements Insert card into PC ISA slot. Set hardware address and interrupt. Connect DeviceNet bus cable and 24V bus power. Configure network via Hilscher setup software.
Usage Notes This is legacy ISA hardware, limited to older industrial PCs. Install proper bus termination resistor at both ends of DeviceNet trunk.
