Technical Specifications Multi-channel DC signal conditioning circuit, backplane bus interface, signal isolation, rack powered.
Functional Features Collects and converts DC analog signals from field sensors, transmits processed data to main processor board, signal fault detection.
Application Scenarios Power plant gas turbine and steam turbine Mark V control system.
Performance Parameters High signal measurement stability, built-in channel self-check, long-term reliable operation in power control cabinet.
Structural Characteristics Rack plug-in PCB board, backplane edge connector, on-board signal conditioning circuit.
Working Principle Receives raw DC analog signals from field transmitters, performs filtering and level conversion, sends digitalized data to CPU board via backplane.
Installation Requirements Install in specified slot of Mark V rack, follow anti-static protection rules, check backplane contact.
Usage Notes Power must be cut before removal. Static protection is mandatory during handling.
