Technical Specifications Rated current: 25A; rated voltage: 480Y/277V AC; 3-pole configuration; thermal-magnetic trip unit; interrupting rating: 10 kA at 480V; trip range: thermal adjustable 80–120% of rated current; magnetic fixed 10× rated current; operating temperature: -30°C to +70°C; UL 489 certified.
Functional Features Integrated overload and short-circuit protection; adjustable thermal trip setting; manual reset operation; visible trip indicator; line and load side terminal connections.
Application Scenarios Motor branch circuit protection, pump and compressor circuit protection, industrial machine power feed protection, control panel motor circuit protection.
Performance Parameters Precise thermal trip calibration; fast magnetic short-circuit response; reliable trip repeatability; low power dissipation.
Material Composition Thermoset molded insulating base, bimetallic thermal element, magnetic trip coil, silver-cadmium contact assembly, glass-filled polyester housing.
Structural Characteristics Molded case construction, front operating handle with trip position, top and bottom screw terminals, standard panel cutout mounting.
Working Principle Under normal operation, current flows through the bimetal element and magnetic coil. Overload current heats the bimetal, deflecting it to trip the mechanism after a time delay. Short-circuit current energizes the magnetic coil instantaneously, tripping the mechanism to interrupt the fault current.
