Technical Specifications 4-axis servo/stepper control, multiple encoder input types, digital I/O, Ethernet and serial ports, 24V DC power supply.
Functional Features Advanced contouring, electronic gearing, camming, position event capture, comprehensive motion error diagnostics.
Application Scenarios Semiconductor handling, precision automation, optical inspection equipment, high-speed packaging machinery.
Performance Parameters High resolution position sampling, fast dynamic response, high synchronization accuracy for multi-axis movement.
Structural Characteristics Metal enclosed DIN rail controller, terminal blocks for power, I/O and encoder signals, communication ports on front panel.
Working Principle Runs stored motion program independently or receives commands from host PC, calculates motion profiles and closes position loop using encoder feedback.
Installation Requirements DIN rail installation inside control cabinet, proper shielding for encoder cables, stable 24V DC power supply.
Usage Notes Backup motion program before parameter modification. Avoid vibration and dust accumulation on controller.
