Technical Specifications PCI interface, supports 3 axes motion control, analog or pulse command output, encoder feedback, digital I/O, powered by PCI slot.
Functional Features Trajectory planning, multi-axis synchronization, electronic cam function, limit switch and home signal processing, motion error monitoring.
Application Scenarios PC-based automation system, CNC equipment, semiconductor processing machinery, precision positioning platforms.
Performance Parameters Fast command response, high resolution position capture, stable trajectory interpolation under high speed movement.
Structural Characteristics Standard PCI form factor circuit board, metal bracket, external terminal board for field signal connection.
Working Principle Communicates with industrial host PC via PCI bus, executes motion programs, outputs control signals to servo drives and reads encoder feedback signals.
Installation Requirements Insert into PCI slot of industrial PC, fix bracket, connect external terminal board for encoder and I/O wiring.
Usage Notes Power off PC before card installation. Avoid electromagnetic interference on feedback cables. Backup motion program regularly.
