Technical Specifications Supports up to 4 axes of servo or stepper motor control, encoder feedback interface, digital input and output channels, serial and Ethernet communication, 24V DC power supply.
Functional Features Realizes point-to-point positioning, linear and circular interpolation, electronic gearing, contour motion, and built-in motion fault detection and status monitoring.
Application Scenarios Automated test equipment, pick-and-place machinery, laser processing equipment, packaging and handling automation.
Performance Parameters High-speed trajectory calculation, smooth motion profile generation, high positioning accuracy, supports continuous 24-hour operation.
Structural Characteristics Compact rack mount controller, metal shielding housing, screw terminal blocks for I/O and encoder wiring.
Working Principle Receives motion commands from host computer, calculates motion trajectory, outputs pulse or analog command signals to drives, reads encoder feedback to close position loop.
Installation Requirements Install inside control cabinet, separate power and signal wiring, use shielded encoder cables, connect 24V DC power supply.
Usage Notes Check wiring before power on. Set axis parameters matching motor and drive. Power off before module maintenance.
