Technical Specifications Ultrasonic measurement principle, 4-20mA output with HART, measuring range up to 10 meters, process connection thread, IP67 housing protection.
Functional Features Non-contact measurement, automatic temperature compensation, false echo suppression, loop powered, simple configuration.
Application Scenarios Liquid storage tank level measurement, silo bulk solid level monitoring, open channel flow measurement, process vessel level control.
Performance Parameters High measurement accuracy, stable signal under process conditions, wide ambient temperature adaptation, low maintenance requirement.
Material Composition PVDF transducer, aluminum housing, electronic circuit module, sealed cable gland.
Structural Characteristics Threaded top mount process connection, integrated transducer, cable outlet, compact field mount design.
Working Principle Emits ultrasonic pulses from the transducer, receives echoes reflected from the product surface, calculates distance based on time of flight and temperature compensation, and outputs corresponding 4-20mA signal.
Installation Requirements Mount vertically on top of tank or vessel, ensure clear sound path to product surface, connect loop powered 4-20mA cable.
Usage Notes Avoid obstructions in sound beam path. Calibrate zero and span after installation. Clean transducer face periodically in dusty applications.
