Technical Specifications SIL rated safety architecture, dual channel design, Foundation Fieldbus interface, force-guided relay outputs, 24V DC power supply.
Functional Features Safety related switching, internal fault detection, redundant channel design, status indication, continuous self diagnostic function.
Application Scenarios Safety instrumented systems, emergency shutdown valve control, process safety interlock, SIL rated fieldbus applications.
Performance Parameters High diagnostic coverage, safe fault response time, certified safety integrity level, reliable contact switching performance.
Material Composition Flame retardant safety housing, force guided relays, safety certified electronic components, gold plated terminal connectors.
Structural Characteristics DIN rail mount safety module, front status and fault LEDs, terminal blocks for safety input and output circuits.
Working Principle Monitors safety commands transmitted over fieldbus, drives dual force-guided relays to perform safe switching, and performs continuous self-diagnosis to detect internal faults and trigger safe state.
Installation Requirements Install in safety dedicated control cabinet, wire safety output circuits per safety specification, configure safety parameters in system engineering tool.
Usage Notes Follow functional safety management procedures for any modification. Perform periodic safety function tests. Do not bypass or disable safety diagnostic functions.
