Technical Specifications 50 ohm characteristic impedance, Foundation Fieldbus H1 compliant, 31.25 kbps bus speed, inline connection design.
Functional Features Bus impedance matching, signal reflection suppression, stable bus communication, compact installation design.
Application Scenarios Foundation Fieldbus H1 network trunk ends, fieldbus segment termination, process control fieldbus system.
Performance Parameters Precise impedance value, wide frequency response, reliable signal integrity improvement.
Material Composition Encapsulated resistor and capacitor network, insulating plastic housing, metal fieldbus connectors.
Structural Characteristics Inline cylindrical design, standard fieldbus connectors at both ends, sealed encapsulated construction.
Working Principle Provides matched terminal impedance at the end of the fieldbus trunk to absorb signal reflections, ensuring clean signal waveform and reliable data communication on the bus.
Installation Requirements Install at each end of the fieldbus trunk segment, connect in series with the bus cable, ensure secure connection.
Usage Notes Always terminate both ends of the trunk. Do not install more than two terminators per segment. Check terminator connection during bus fault troubleshooting.
