Technical Specifications Foundation Fieldbus H1 compatible, 50 ohm termination impedance, built-in surge suppression, 24V DC pass through, DIN rail mounting.
Functional Features Bus impedance matching, transient surge protection, signal integrity improvement, status indication, easy installation.
Application Scenarios Industrial fieldbus network, hazardous area fieldbus segments, plant process control network.
Performance Parameters Accurate termination impedance, high surge energy rating, reliable bus signal quality improvement.
Material Composition Flame retardant plastic housing, surge protection components, precision termination network, copper terminal blocks.
Structural Characteristics DIN rail mount module, front status LED, terminal blocks for bus connection, compact housing.
Working Principle Provides matched 50 ohm impedance to terminate the fieldbus segment, and incorporates surge suppression components to divert transient overvoltage away from bus devices.
Installation Requirements Mount on DIN rail at fieldbus segment end, wire bus cable to terminal block, connect protective ground.
Usage Notes Verify only one terminator at each end of segment. Inspect surge protection after lightning event. Follow hazardous area installation standards if applicable.
