Technical Specifications Dual fiber optic ports, industrial Ethernet protocol, optical fiber transmission distance up to specified length, 24V DC power supply, DIN rail mounting.
Functional Features Full duplex data transmission, electrical isolation between local and remote sides, surge immunity, link status monitoring.
Application Scenarios Long distance DCS system extension, high electromagnetic interference plant area, inter-building control communication.
Performance Parameters High bandwidth data transmission, stable optical link, low bit error rate, wide operating temperature range.
Material Composition Metal shielding housing, optical transceiver components, fiber optic connectors, signal processing circuit board.
Structural Characteristics Compact DIN rail mount design, front optical ports and status LEDs, rear power and electrical interface terminals.
Working Principle Converts electrical control signals into optical signals for transmission through fiber optic cable, and converts received optical signals back into electrical signals, achieving noise-immune long distance communication.
Installation Requirements Mount on DIN rail in control cabinet, connect single mode / multi mode fiber cable, match communication parameters with peer device.
Usage Notes Clean fiber connectors before mating. Avoid excessive bending of fiber cable. Verify link status after installation.
