Technical Specifications Multiple analog and pulse input channels, supports differential pressure, temperature and pressure measurement, Ethernet and serial communication, data logging function.
Functional Features Multi-variable flow calculation, AGA / API standard flow algorithms, data logging and archiving, remote communication, alarm and event recording.
Application Scenarios Natural gas custody transfer metering, oil pipeline flow measurement, wellhead production monitoring, process flow totalization.
Performance Parameters High calculation accuracy, reliable data storage, fast communication response, 24/7 continuous operation capability.
Material Composition Metal industrial chassis, flame retardant plastic front panel, printed circuit board, sealed terminal compartment.
Structural Characteristics Panel or rack mount design, front display and keypad, rear terminal blocks for input, output and communication.
Working Principle Acquires flow, pressure and temperature signals from field transmitters, executes standard flow calculation algorithms to compute corrected flow rate and totalized volume, and stores and transmits flow data.
Installation Requirements Mount in control room panel or field enclosure, connect field sensor signals, configure communication parameters, verify calculation formulas.
Usage Notes Calibrate input channels periodically. Backup flow data and configuration regularly. Ensure power supply stability for data integrity.
