Technical Specifications 11mm probe; CON021 series converter assembly; 0~4mm measuring range; analog voltage output; probe temperature -40~180°C.
Functional Features Non-contact displacement measurement. Signal conditioning and cable fault detection by converter assembly.
Application Scenarios Large steam turbine, gas turbine, heavy-duty compressor and generator protection system.
Performance Parameters Wide linear range; High temperature probe; Analog output proportional to gap distance.
Structural Characteristics Metal probe, coaxial cable, DIN rail mounted CON021 converter assembly with terminals and LED indicators.
Working Principle Probe coil generates eddy current on metal shaft. The converter assembly detects impedance variation and converts gap change to analog voltage signal.
Installation Requirements Install probe and adjust air gap. Connect probe cable to converter assembly. Wire power and analog output to monitoring module.
Usage Notes Use original matched cable assembly. Perform calibration before commissioning. Protect cable from mechanical damage.
