Technical Specifications 8mm eddy current probe; CON021 converter; 0~2mm measuring range; Output voltage proportional to displacement; Operating temperature -40~180°C for probe.
Functional Features Non-contact shaft displacement measurement. Converter supplies probe excitation and outputs analog voltage signal for monitoring system. Cable break detection.
Application Scenarios Turbine, compressor, generator, large rotating machinery vibration and axial position monitoring.
Performance Parameters Linear displacement-voltage characteristic; Cable fault monitoring; High temperature probe capability.
Structural Characteristics Probe with coaxial cable; CON021 DIN rail mounted converter with terminal block and status LED.
Working Principle Probe coil generates eddy current on shaft surface. CON021 converter supplies high frequency excitation, detects coil impedance change and outputs analog voltage proportional to gap distance.
Installation Requirements Mount probe in bracket and set air gap. Connect probe cable to CON021 converter. Wire converter power and analog output to monitoring system.
Usage Notes Use specified length of matched cable. Check cable integrity. Calibrate gap voltage during commissioning.
