Technical Specifications 16 analog input channels, 4-20mA current signal, 16-bit resolution, 24V DC field loop power, DeltaV backplane interface.
Functional Features Multi-channel signal acquisition, signal filtering, channel fault diagnosis, open circuit detection, HART signal pass-through support.
Application Scenarios Process variable measurement, temperature, pressure, flow and level signal acquisition, industrial process control system.
Performance Parameters High measurement accuracy, low signal drift, fast channel response, built-in surge suppression.
Material Composition Flame retardant plastic housing, analog conditioning circuit board, analog to digital converter, gold-plated backplane connector.
Structural Characteristics Rack plug-in I/O module, front terminal block for field wiring, rear backplane bus connector.
Working Principle Receives 4-20mA analog signals from field transmitters, conditions and converts the signals into digital data, and transmits the data to DeltaV controller via backplane bus.
Installation Requirements Install in DeltaV I/O rack slot, connect shielded analog signal cables, configure channel type in system configuration.
Usage Notes Use shielded twisted pair cables for analog signals. Separate signal wiring from power cables. Verify loop power supply polarity.
