Technical Specifications Foundation Fieldbus H1 protocol, 31.25 kbps communication rate, 24V DC power supply, DeltaV backplane bus interface, 4 fieldbus segments.
Functional Features Fieldbus network management, device communication scheduling, bus power management, device diagnostics, hot swap support.
Application Scenarios DeltaV DCS system, process control fieldbus network, plant instrument and actuator communication.
Performance Parameters Stable real-time communication, high device compatibility, fast fault detection, continuous network operation.
Material Composition Flame retardant plastic housing, fiberglass communication circuit board, gold-plated backplane connector, bus isolation components.
Structural Characteristics Rack plug-in card structure, front status LED indicators, rear backplane connector and fieldbus terminals.
Working Principle Acts as a link between DeltaV controller and Foundation Fieldbus devices, converts system commands into fieldbus protocol and transmits field device data back to the controller.
Installation Requirements Insert into DeltaV I/O rack slot, connect fieldbus trunk cable, configure device address, implement system grounding.
Usage Notes Terminate each fieldbus segment properly. Use certified fieldbus cable. Avoid running parallel to high voltage power cables.
