Technical Specifications High-speed DSP processor, support multi-axis coordinated motion, abundant digital I/O, Ethernet communication interface, expandable daughter card slot. Operating temperature:0°C ~ +55°C.
Functional Features High-speed trajectory interpolation, multi-task program operation, electronic cam and gearing function, fault monitoring, Ethernet host communication, safety watchdog relay output.
Application Scenarios High-speed pick-and-place equipment, CNC machinery, packaging automation, precision cutting and inspection machines.
Performance Parameters Fast servo loop update, high trajectory smoothness, flexible electronic cam function. Operating temperature:0~+55°C.
Structural Characteristics Rack mount controller board, multiple I/O and encoder connectors, Ethernet port, onboard memory and power circuit.
Working Principle Calculate motion trajectory in real time, output servo commands to drives, collect position feedback, run background PLC logic and communicate with host HMI or PC over Ethernet.
Installation Requirements Install inside control cabinet. Connect 24V DC power, encoder cables and drive control wiring. Download motion program and axis setup.
Usage Notes Validate limit switch and watchdog safety logic before running automatic cycle. Keep high-current power cables separate from low-level encoder signals.
