Technical Specifications Multi-channel digital input, 24V DC signal, X20 bus, input signal filtering.
Functional Features Field switch signal acquisition, signal filtering, channel status transmission to CPU.
Application Scenarios General factory automation, machine tool, packaging machinery signal collection.
Performance Parameters Stable signal sampling, anti-chatter filtering.
Material Composition Plastic housing, input circuit PCB, gold-plated bus connector, terminal blocks.
Structural Characteristics X20 modular I/O, front wiring terminals, rear X20 bus connector, DIN rail mounting.
Working Principle Detect on-off state of field 24V DC switch signal, convert to digital data and send to X20 CPU via internal bus.
Installation Requirements Mount on DIN rail, connect X20 bus, wire field sensor and switch signal.
Usage Notes Check input signal voltage range. Prevent wiring short circuit.
