Technical Specifications High-speed pulse input, encoder signal interface, X20 bus, 24V DC power supply.
Functional Features Pulse counting, frequency measurement, encoder position acquisition, hardware trigger function.
Application Scenarios Positioning machine, material cutting equipment, conveyor speed measurement.
Performance Parameters High counting frequency, hardware high-speed processing, anti-pulse interference.
Material Composition Plastic housing, high-speed counting PCB, gold-plated bus connector, terminal blocks.
Structural Characteristics X20 modular design, front signal terminals, rear X20 bus connector, DIN rail mounting.
Working Principle Receive pulse signals from encoder or pulse sensor, count pulse number and transmit position and frequency data to X20 CPU.
Installation Requirements Install on DIN rail, connect X20 bus, wire encoder shielded cable.
Usage Notes Configure counting mode in PLC program. Separate pulse cable from power cable.
