Technical Specifications Multi-channel temperature input, support PT100, thermocouple, X20 bus, 24V DC power.
Functional Features Temperature signal acquisition, cold junction compensation, signal filtering, channel fault detection.
Application Scenarios Plastic injection machine, furnace temperature monitoring, packaging and food machinery.
Performance Parameters High temperature measurement accuracy, built-in open circuit detection.
Material Composition Plastic housing, signal processing PCB, gold-plated bus connector, terminal blocks.
Structural Characteristics Modular X20 design, front terminal block, rear bus connector, DIN rail mounting.
Working Principle Receive resistance or millivolt signal from temperature sensor, convert signal to temperature value and send data to X20 CPU.
Installation Requirements Install on DIN rail, connect X20 bus, wire temperature sensor to module terminals.
Usage Notes Use dedicated temperature compensation cable. Check sensor type configuration in PLC program.
