Technical Specifications Multi-channel analog input, 4-20mA / voltage signal, X20 bus interface, 24V DC power supply.
Functional Features Analog signal acquisition, signal filtering, channel fault diagnosis, data transmission to X20 CPU.
Application Scenarios Factory automation, packaging machine, plastic machinery, process monitoring.
Performance Parameters High sampling precision, built-in surge protection, wide working temperature.
Material Composition Plastic housing, fiberglass PCB, gold-plated X20 bus connector, terminal blocks.
Structural Characteristics X20 series modular structure, front wiring terminals, rear bus connector, DIN rail mounting.
Working Principle Collect analog signals from field transmitters, convert analog signal to digital data and transmit to X20 CPU via internal bus.
Installation Requirements Clip on DIN rail, connect to X20 bus backplane, wire field signal to terminal block.
Usage Notes Use shielded cable for analog signal. Avoid wiring parallel with high-power cable.
