Technical Specifications 24VDC logic power supply. Differential encoder feedback interface. Analog command output. Galvanic isolation between control side and drive side. Operating temperature:0°C ~ +55°C.
Functional Features Transmit motion control command to servo drive. Receive encoder position feedback signal. Signal isolation protection. Axis status monitoring and fault reporting.
Application Scenarios Matching with CLC-D02 motion controller for machine tool, automation equipment servo axis signal connection.
Performance Parameters High-speed differential signal transmission, anti-interference for encoder feedback. Operating temperature:0~+55°C.
Structural Characteristics Rack mount interface board, screw terminals for drive wiring, backplane connector to CLC controller, signal conditioning circuit.
Working Principle Convert digital motion command from CLC controller into analog servo setpoint, receive encoder feedback signal from servo motor and transmit back to motion controller for closed-loop calculation.
Installation Requirements Install in the same DDS rack with CLC-D02. Connect shielded encoder and command cables to servo drive. Complete axis parameter configuration.
Usage Notes Use shielded twisted pair for encoder wiring. Keep signal cables separated from high-power drive cables.
