BEI H38D-1800-ABZC-8830-LED-SC-UL Optical Encoder with LED Status Indicator
The BEI H38D-1800-ABZC-8830-LED-SC-UL is a rugged optical encoder module with integrated LED signaling, designed for precision motion control and position feedback in industrial automation systems. Engineered for demanding environments, it provides accurate rotational data while offering visual status indication for equipment operators in manufacturing, robotics, and energy applications.
Technical Specifications
| Parameter | Value |
| Model Number | H38D-1800-ABZC-8830-LED-SC-UL |
| Brand | BEI Sensors |
| Type | Optical Encoder with LED Indicator |
| Input Voltage | 10-30V DC |
| Resolution | 1800 PPR |
| Accuracy | ±0.05° |
| Operating Temperature | -40°C to +85°C |
| Protection Rating | IP67 |
| Communication | ABZC Quadrature Output |
| Dimensions | 120mm × 75mm × 30mm |
| Weight | 0.5 kg |
Applications & Compatibility
This multifunction encoder is ideal for CNC machinery, servo motor feedback systems, robotic positioning, and conveyor control where both precise motion data and visual status indication are required. The integrated LED indicators provide immediate machine state feedback in four colors (red/green/yellow/blue) with 120° viewing angle. Compatible with BEI’s H38 series mounting accessories and commonly interfaces with PLCs from Siemens, Allen-Bradley, and Omron.
Apex Automation Solutions
Since 2014, Apex Automation has specialized in ready-to-ship industrial automation solutions. Our technical experts provide comprehensive pre-sales consultation to match your application requirements and professional post-sales support with 1-year warranty on all products. We offer competitive pricing on this BEI encoder and thousands of other industrial components. Can’t find your specific model? Contact our engineers via WhatsApp for immediate assistance with special requests or custom configurations.
Get Pricing & Technical Support:
Email: anikaqx@gmail.com |
All products include 1-year performance warranty
