Technical Specifications Equipped with industrial-grade processor, high brightness touch screen, multiple Ethernet ports, USB interfaces and serial communication ports. Supports wide range DC power input, operating temperature range from 0°C to +55°C.
Functional Features Combines human-machine interface and industrial controller. Supports TwinCAT real-time runtime system, can perform logic control, motion control and data visualization simultaneously. High anti-vibration and anti-interference capability for industrial field.
Application Scenarios Used in production line control, packaging machinery, material handling equipment, and general factory automation cabinet HMI & control station.
Performance Parameters Real-time operating system support, fast response for field signals, long service life of touch panel, stable continuous operation 24/7.
Structural Characteristics Cabinet front panel installation design, compact structure, aluminum alloy housing for heat dissipation, sealed front face to resist dust and splash.
Working Principle Runs TwinCAT software to collect field signals via bus connection, executes control logic, displays real-time process data on touch screen and receives operation input from operators.
Installation Requirements Install inside control cabinet, ensure adequate ventilation and heat dissipation. Fix by panel mounting clamps. Use specified DC power supply.
Usage Notes Do not touch the touch screen with sharp objects. Avoid strong vibration and corrosive gas environment. Cut off power before disassembly or wiring.
