Technical Specifications Digital processor core, voltage and current measurement channels, excitation output drive interface, 24V DC auxiliary power, panel status indicators.
Functional Features Real-time monitoring of generator terminal voltage, automatic adjustment of excitation current, overvoltage and overcurrent protection, alarm and fault recording functions.
Application Scenarios Synchronous generators in power stations, backup power generating sets, hydroelectric and diesel generator units.
Performance Parameters Fast voltage regulation response, high regulation precision, stable operation under load fluctuation, fault event recording.
Structural Characteristics Panel mounting compact unit, metal casing, terminal blocks for power, voltage and excitation wiring.
Working Principle Samples generator voltage and current signals in real time, calculates required excitation output through control algorithm, adjusts excitation to maintain constant generator terminal voltage.
Installation Requirements Mount on control cabinet front panel, isolate high voltage wiring, connect PT and CT signals correctly.
Usage Notes High voltage risk during commissioning. Verify PT and CT wiring polarity before power-on. Set protection parameters according to generator rating.
