Technical Specifications Three-phase AC power supply, standard industrial voltage rating, IP55 protection degree, class F insulation, 50/60 Hz frequency compatibility, foot mounting configuration.
Functional Features High starting torque, low noise operation, high efficiency energy saving design, continuous duty rating, wide ambient temperature adaptation.
Application Scenarios Pumps, fans, compressors, conveyors, machine tools and general industrial machinery drive systems.
Performance Parameters High power density, stable speed under load variation, low vibration level, long service life under continuous operation.
Material Composition Cast iron motor housing, silicon steel stator lamination, copper winding, steel output shaft, aluminum fan blade.
Structural Characteristics Foot mounted cylindrical frame, integrated terminal box on top, rear fan cover with cooling fins, solid output shaft.
Working Principle Three-phase stator winding generates rotating magnetic field when energized, which drives the squirrel-cage rotor to rotate and output mechanical torque through the shaft.
Installation Requirements Mount on rigid base frame, align coupling with driven equipment, connect power cable through terminal box, implement protective grounding.
Usage Notes Lubricate bearings at specified intervals. Check winding temperature during continuous operation. Keep cooling fins clean and unobstructed.
