Technical Specifications PROFIBUS DP slave interface, DP-V0 compliant; CANopen slave interface, DS-301 compliant; maximum 512 bytes input and 512 bytes output data size; 24V DC power supply; operating temperature -25°C to +55°C; DIN rail mounting; IP20 rating.
Functional Features Bi-directional data mapping between PROFIBUS DP and CANopen; configurable I/O data size; rotary switch for node address setting; galvanic isolation between networks; built-in status diagnostics.
Application Scenarios PROFIBUS and CANopen system interconnection, multi-network factory automation, robot system integration, mixed bus control systems.
Performance Parameters Deterministic data exchange; low protocol conversion latency; stable communication on both networks; high reliability.
Material Composition Industrial plastic enclosure, dual-protocol communication circuit board, isolated bus transceivers, gold-plated connectors.
Structural Characteristics Compact DIN rail mount form factor; front network status LEDs; rotary address switches; 9-pin D-sub PROFIBUS connector; 9-pin D-sub CANopen connector.
Working Principle Acts as an independent slave on both PROFIBUS DP and CANopen networks. It cyclically exchanges I/O data with both masters and maps data between the two networks, enabling transparent data exchange between the two bus systems.
Installation Requirements Mount on standard DIN rail; connect PROFIBUS and CANopen bus cables; set node addresses for both networks via rotary switches; configure data mapping via Anybus Configuration Manager.
Usage Notes Terminate both bus networks with appropriate termination resistors; verify baud rate settings match each network; perform data mapping test during commissioning.
