Technical Specifications DeviceNet slave interface; PROFIBUS DP slave interface; 24V DC power supply; 150mA maximum current consumption; operating temperature -25°C to +55°C; DIN rail mounting; IP20 enclosure; CE, RoHS certified.
Functional Features Bi-directional protocol conversion between DeviceNet and PROFIBUS DP; configurable I/O data mapping; automatic baud rate detection; galvanic isolation between both networks; status indication.
Application Scenarios DeviceNet device integration into PROFIBUS systems, multi-vendor system interconnection, factory network migration, mixed protocol automation systems.
Performance Parameters Fast data exchange between networks; low conversion latency; reliable communication; high MTBF.
Material Composition Industrial plastic housing, fiberglass dual-protocol circuit board, isolated transceivers, gold-plated connectors.
Structural Characteristics Compact DIN rail mount module; front status LEDs for both networks; 5-pin DeviceNet connector; 9-pin PROFIBUS connector; power connector.
Working Principle Operates as a protocol bridge between DeviceNet and PROFIBUS DP networks. It maps I/O data between the two networks, converting message formats and enabling data exchange between devices on both bus systems.
